Smart Wash reoveepump/tõstesüsteem

Kirjeldus

The system has 3 inlet connections (1 1/8 inch or 1 1/2 inch, 3/4 or 1 inch, 3/4 inch), which means that other devices can be connected in addition to the Smart Wash Dimensions 335mm x 210mm x 110mm. The connection for the wastewater hose to the gray water tank is 19mm or 3/4 inch and has an integrated check valve. Since the washer-dryer itself does not have a built-in wastewater pump, it may be necessary to install a corresponding lifting pump. This is particularly the case if the washer-dryer is to be connected to the gray water tank of the motorhome or camper, but the water outlet of the machine at the installation site is lower than the upper edge of the gray water tank. The lifting pump overpressures this height difference up to a maximum delivery height of 1.40 m. In most washing programs, the washer-dryer drains the entire water content (approx. 12 liters) from the machine within a good minute. A lifting pump to be installed must therefore have a delivery rate of at least 10 to 12 liters per minute. This pump system is a fully automatic lifting pump that switches on when water is drained from the machine and switches off again when the water is pumped out.
